JWST's First Exoplanet Atmosphere: What WASP-39b Revealed
Photo: Fahrettin Turgut / Pexels
On July 12, 2022, a paper posted to arXiv — before formal peer review, because the team wanted the community to see it immediately — showed a graph with a dip in it. The dip was centered at 4.3 micrometers, the precise wavelength where carbon dioxide absorbs infrared light. The graph came from a spectrum of WASP-39b, a hot Jupiter 700 light-years from Earth, observed by the James Webb Space Telescope. It was the clearest direct detection of CO₂ in any exoplanet atmosphere ever made, and it proved that JWST could do chemistry on planets orbiting other stars — a capability that opens the path to detecting biosignatures on potentially habitable worlds.
What Is WASP-39b and Why Was It the First Target?
WASP-39b is a hot Jupiter — a gas giant roughly the mass of Saturn and the size of Jupiter, orbiting its host star at a distance of only 0.049 AU, completing one orbit every 4.05 Earth days. It was discovered in 2011 by the Wide Angle Search for Planets (WASP) survey.
Hot Jupiter — a class of gas giant exoplanet with orbital periods shorter than 10 days, placing them so close to their host stars that their equilibrium temperatures typically exceed 1,000 K; tidally locked, with one hemisphere perpetually facing the star and the other in permanent night.
WASP-39b's equilibrium temperature is approximately 1,100 K (around 830°C), hot enough to melt aluminum but cool enough — by hot Jupiter standards — to retain a relatively cloud-free atmosphere in the infrared wavelengths where JWST operates best. Heavily clouded hot Jupiters are poor transmission spectroscopy targets because clouds block the spectral features from underlying molecular absorption. WASP-39b's relatively clear skies made it a priority target for early JWST observations.
The planet also orbits a quiet, Sun-like G-type star, which simplifies the analysis. Stars that flare frequently, or that have complex starspot distributions, can imprint false spectral features on transmission spectra, complicating the interpretation. WASP-39's stellar activity level is low enough that this contamination is manageable.
The combination of factors — large planet radius, clear atmosphere, quiet host star, frequent transits — made WASP-39b the ideal benchmark for demonstrating JWST's exoplanet spectroscopy capabilities.
Source: Faedi et al., Astronomy and Astrophysics (2011) — Discovery paper for WASP-39b, reporting the planetary mass, radius, orbital parameters, and initial characterization of the host star.
Transmission Spectroscopy: How to Read an Atmosphere from 700 Light-Years Away
The technique that JWST used to detect CO₂ in WASP-39b's atmosphere is transmission spectroscopy, and it works with an elegance that makes it worth understanding in detail.
When a planet transits its host star — passes in front of it from our perspective — it blocks a small fraction of the star's light, producing the characteristic dimming of a transit light curve. The fraction blocked depends on the planet's radius: a larger apparent radius blocks more light. For a planet with an atmosphere, the atmosphere is not opaque — at wavelengths where atmospheric molecules strongly absorb light, the atmosphere appears thicker, and the planet's apparent radius is larger. At wavelengths where the atmosphere is transparent, the apparent radius is smaller.
Transmission spectroscopy — a technique for characterizing exoplanet atmospheres by measuring the wavelength-dependent transit depth as a planet passes in front of its host star; wavelengths at which the atmosphere absorbs strongly produce deeper transits (larger apparent planet radius), revealing the molecular composition of the atmosphere.
Think of it like holding a piece of colored glass in front of a lamp. The glass is transparent at most wavelengths, but at specific colors it absorbs, appearing darker. Now measure how much of the lamp is blocked at each wavelength. The pattern of absorptions is the chemical fingerprint of the glass — or in the case of an exoplanet, the fingerprint of its atmosphere.
The scale of the effect is tiny. For WASP-39b, the CO₂ feature at 4.3 micrometers causes the transit depth to increase by roughly 50 parts per million (ppm) relative to adjacent wavelengths. This means the planet blocks about 50 parts per million more of the star's light at 4.3 micrometers than at nearby wavelengths. Detecting this requires:
- Observing the transit multiple times (or for long enough to average down noise)
- A telescope with large collecting area (JWST's primary mirror is 6.5 m in diameter)
- Detectors sensitive in the mid-infrared (JWST's MIRI and NIRSpec instruments)
Hubble and Spitzer detected water vapor in hot Jupiter atmospheres, but their sensitivity and wavelength coverage were insufficient for clear molecular detections across the full infrared spectrum. JWST's combination of a large mirror, stable thermal environment (it orbits the L2 Lagrange point, 1.5 million km from Earth, shielded from solar and terrestrial thermal fluctuations), and advanced detectors shifts the sensitivity floor by roughly an order of magnitude.
Source: JWST Transiting Exoplanet Community Early Release Science Team, Nature (2023) — Full early release science results for WASP-39b including the CO₂ detection paper and companion papers covering NIRSpec, NIRCam, and MIRI observations, published as a coordinated package.
The CO₂ Detection: What the Spectrum Actually Shows
The July 2022 preprint presented a spectrum covering 3.0 to 5.5 micrometers obtained with JWST's Near-Infrared Spectrograph (NIRSpec) in its PRISM mode. This wavelength range is critical because it includes the 4.3-micrometer CO₂ band, which has no competing absorption from water vapor or methane in this spectral region.
The spectrum showed a broad, deep absorption feature centered precisely at 4.3 micrometers — the carbon dioxide fundamental band — standing out clearly above the noise. The detection significance was reported at greater than 26 sigma: the feature is 26 standard deviations above the noise floor, essentially impossible to attribute to statistical fluctuation or systematic error.
The shape and depth of the feature encode more than just the presence of CO₂. By fitting atmospheric models to the spectrum, the team constrained the CO₂ abundance in WASP-39b's atmosphere. The measured volume mixing ratio was consistent with roughly 10–20 times solar carbon abundance relative to oxygen — implying that WASP-39b formed in a region of the protoplanetary disk rich in carbon-bearing solids and then migrated inward to its current close orbit.
Carbon-to-oxygen (C/O) ratio — the ratio of carbon atoms to oxygen atoms in a planet's atmosphere; predicted to depend on where the planet formed in the protoplanetary disk relative to the "ice lines" for water, CO₂, and CO; a sub-solar C/O ratio suggests the planet accreted oxygen-rich icy material beyond the water ice line.
The C/O ratio measured for WASP-39b places it in a regime consistent with formation beyond the water ice line — the distance from the host star at which water condenses into ice, typically several AU in a typical protoplanetary disk. This supports the migration hypothesis: WASP-39b formed as a cold-disk gas giant and subsequently drifted inward through gravitational interactions with the disk or with other planets.
Source: JWST Transiting Exoplanet Community ERS Team, Nature (2023) — CO₂ detection paper reporting the >26-sigma detection, atmospheric retrieval constraints on molecular abundances, and formation history implications.
Sulfur Dioxide and Photochemistry: The Unexpected Discovery
The CO₂ detection was the headlined result, but a companion paper from the same observing program reported something scientifically more surprising: the detection of sulfur dioxide (SO₂) in WASP-39b's atmosphere, formed not by equilibrium chemistry but by photochemistry.
Photochemistry refers to chemical reactions driven by energetic photons — ultraviolet light from the host star — rather than by thermal equilibrium. In Earth's stratosphere, photochemistry produces ozone. On WASP-39b, the UV irradiation from the host star breaks apart water and hydrogen sulfide (H₂S) molecules in the upper atmosphere, releasing reactive sulfur atoms that combine with oxygen radicals to form SO₂.
Photochemistry (planetary atmospheres) — chemical reactions in an atmosphere driven by ultraviolet or visible photons from the host star, producing non-equilibrium molecules that would not be present in a purely thermally-driven chemistry; relevant to both hot Jupiter atmospheres and the search for biosignatures on habitable zone planets.
This matters enormously for the search for life. Biosignature gases like ozone (O₃) and methane (CH₄) are also non-equilibrium photochemical products. Detecting SO₂ through photochemistry on WASP-39b is a direct demonstration that JWST can detect photochemically produced molecules — molecules generated by atmospheric physics rather than by simple equilibrium — in exoplanet atmospheres. This is exactly the class of molecules that could flag biology on a temperate planet.
The SO₂ detection also demonstrates that JWST's sensitivity is sufficient to detect molecules at abundance levels of roughly 10 parts per million in a planetary atmosphere. Current estimates of the SO₂ mole fraction in WASP-39b's upper atmosphere range from ~10–40 ppm — comparable to the level at which some biosignature gases (such as nitrous oxide, N₂O) would need to be detected on a terrestrial exoplanet to be identified unambiguously.
Source: Tsai et al., Nature (2023) — Detection of SO₂ in WASP-39b's atmosphere via JWST NIRSpec, interpreted as the first detection of photochemistry in an exoplanet atmosphere; photochemical model fitting the SO₂ abundance to UV-driven reactions.
The Full WASP-39b Spectral Portrait
The early release science program for WASP-39b was not a single observation — it was a coordinated campaign using four different JWST instruments and modes to cover the full wavelength range from 0.6 to 12 micrometers. Different instruments covered different spectral ranges:
| Instrument/Mode | Wavelength Range | Key Molecules Detected |
|---|---|---|
| NIRCam (F322W2 grism) | 2.4–4.0 μm | CO₂ (partial), H₂O, CO |
| NIRSpec PRISM | 0.6–5.3 μm | CO₂, H₂O, CO, Na, K |
| NIRSpec G395H | 2.8–5.3 μm | CO₂, SO₂, H₂O |
| NIRISS SOSS | 0.6–2.8 μm | H₂O, K, CO₂ (partial) |
The combined spectrum, covering the full near-infrared and reaching into the mid-infrared with MIRI, represents the most complete exoplanet atmosphere spectrum ever obtained. It detects CO₂, water vapor, carbon monoxide, sodium, potassium, and SO₂ — a chemical census that constrains the bulk composition, thermal structure, and photochemical environment of the planet simultaneously.
Atmospheric retrieval models — software frameworks that fit millions of model spectra to the observed data to derive posterior probability distributions for temperature, molecular abundances, and cloud properties — found that the WASP-39b spectrum is broadly consistent with a hydrogen-dominated atmosphere (as expected for a gas giant) with super-solar metallicity (more heavy elements than the Sun has, proportionally) and evidence for a non-uniform cloud distribution that is thicker on the night side.
Source: Alderson et al., Nature (2023) — NIRSpec G395H analysis of WASP-39b covering CO₂ and SO₂ detections with detailed atmospheric retrieval modeling.
What Hot Jupiter Atmospheres Tell Us About Planet Formation
WASP-39b is one of the best-studied examples of a class of objects — hot Jupiters — that were not expected to exist when they were discovered in the mid-1990s. Before the discovery of 51 Pegasi b in 1995, the standard model of planetary formation predicted that gas giants form in cold regions of protoplanetary disks, well beyond the water ice line, where volatile ices can contribute to the solid material that seeds planetary growth. A gas giant orbiting at 0.05 AU should not exist.
The explanation is disk migration — the process by which a planet formed in the outer disk loses angular momentum through gravitational interaction with the protoplanetary disk gas and drifts inward. Migration theory predicts that some gas giants will be stranded at close orbital distances when the disk dissipates, leaving them as hot Jupiters. The chemical composition of hot Jupiter atmospheres — specifically the C/O ratio and the enrichment of heavy elements — is a diagnostic of where in the disk the planet formed before it migrated.
WASP-39b's atmospheric composition is consistent with formation beyond the water ice line and inward migration. The high-metallicity atmosphere (enriched in heavy elements relative to solar) suggests substantial accretion of icy planetesimals during formation — a signature of the outer disk.
Comparing WASP-39b with other hot Jupiters studied by Hubble and now JWST reveals a diversity of atmospheric compositions that maps onto formation location predictions. Planets with solar or sub-solar C/O ratios likely accreted oxygen-rich ices; those with super-solar C/O may have formed in carbon-enriched disk regions. Building a population of atmospheric composition measurements across a range of planet masses and orbital architectures is a primary goal of JWST's exoplanet program.
Source: Madhusudhan, Annual Review of Astronomy and Astrophysics (2019) — Review of exoplanet atmospheric characterization, covering retrieval methods, the C/O ratio as a formation diagnostic, and the state of the field before JWST.
The Path to Habitable Zone Atmospheres
WASP-39b is not a candidate for life — at 1,100 K, its atmosphere is far too hot. But it is the proof-of-concept instrument validation that enables JWST to attempt the much harder problem of characterizing atmospheres on smaller, cooler, potentially habitable worlds.
The TRAPPIST-1 system — seven rocky planets orbiting a nearby red dwarf star, three of them in the habitable zone — is the primary long-term target for JWST atmospheric characterization of potentially habitable planets. These planets are 40 light-years from Earth and produce transmission spectroscopy signals roughly 10–50 times smaller than WASP-39b's. Detecting a biosignature gas like ozone or methane in a TRAPPIST-1 planet's atmosphere with JWST requires many transit observations stacked together, and the total signal may still be marginal.
But the WASP-39b result confirmed that JWST's systematic noise floor is lower than pre-launch estimates, that atmospheric retrievals can be performed reliably, and that photochemically-produced molecules are detectable. Each of these validations is a building block toward the more demanding science that the mission's ultimate goals require.
Understanding the context of JWST's exoplanet work sits alongside the broader question of how exoplanet atmospheres and biosignatures are detected, and the possibility of life around other stars connects to the ongoing search for habitable conditions on nearby moons, discussed in Enceladus and its hydrothermal vents.
Source: Lustig-Yaeger et al., Nature Astronomy (2022) — Pre-launch assessment of JWST's ability to detect atmospheric features on TRAPPIST-1 planets, estimating the number of transits required for biosignature detection under various atmospheric scenarios.
The Takeaway
The CO₂ detection in WASP-39b's atmosphere in July 2022 was a proof of capability, not an endpoint. JWST demonstrated that it could read the chemical fingerprint of an atmosphere on a planet orbiting another star with a clarity no previous observatory could approach. The detection of SO₂ — a photochemically produced molecule requiring understanding of UV-driven chemistry rather than simple equilibrium — showed that the telescope could detect exactly the class of non-equilibrium molecules that biosignatures belong to. WASP-39b is not a life-bearing world, but the science developed studying it is the methodological template for the science that might eventually find one that is.
Frequently Asked Questions
Q: What is transmission spectroscopy and how does it work?
A: Transmission spectroscopy measures how much starlight passes through a planet's atmosphere during a transit. At wavelengths where atmospheric molecules absorb strongly, the planet's apparent size is larger (more light is blocked). At transparent wavelengths, the apparent size is smaller. By measuring transit depth as a function of wavelength, astronomers build a spectrum of the atmosphere's molecular absorbers, revealing its chemical composition.
Q: Why was CO₂ detection in WASP-39b so significant?
A: It was the clearest, highest-significance detection of a molecule in any exoplanet atmosphere at the time, at greater than 26 sigma. More importantly, it demonstrated that JWST could perform precise infrared spectroscopy at the parts-per-million level required for atmosphere characterization, validating the telescope's performance for future science including the search for biosignatures on smaller, cooler planets.
Q: What is sulfur dioxide doing in WASP-39b's atmosphere?
A: SO₂ in WASP-39b is produced by photochemistry: ultraviolet radiation from the host star breaks apart hydrogen sulfide and water, releasing reactive sulfur and oxygen radicals that recombine as SO₂. This is the first direct detection of photochemistry in an exoplanet atmosphere and demonstrates that JWST can detect non-equilibrium molecules — the same class as potential biosignatures like ozone and methane.
Q: What does the C/O ratio tell us about a planet?
A: The carbon-to-oxygen ratio in a planet's atmosphere encodes where the planet formed in the protoplanetary disk. Regions inside the water ice line are oxygen-enriched; regions outside are relatively carbon-enriched. A sub-solar C/O ratio in WASP-39b suggests it formed beyond the water ice line and accreted oxygen-rich icy solids before migrating inward to its current close orbit.
Q: Is WASP-39b a good candidate for life?
A: No. At an equilibrium temperature of approximately 1,100 K and orbiting at 0.049 AU from its host star, WASP-39b is a hot, tidally locked gas giant with no solid surface and an atmosphere hostile to any known biology. Its value is as an atmospheric benchmark — the best-studied exoplanet atmosphere available — rather than an astrobiological target.
Q: Which JWST instruments were used to study WASP-39b?
A: The early release science campaign used NIRSpec (in both PRISM and G395H grating modes), NIRCam (in wide-field slitless spectroscopy mode), and NIRISS (in single object slitless spectroscopy mode). Together these instruments covered wavelengths from 0.6 to approximately 12 micrometers, providing the most complete exoplanet atmosphere spectrum ever obtained.
Q: When will JWST study TRAPPIST-1 planets in detail?
A: JWST has already begun observing TRAPPIST-1 planets in its first years of operation. Early results from TRAPPIST-1b and TRAPPIST-1c (the two innermost, non-habitable-zone planets) placed upper limits on atmospheric thickness, suggesting these inner planets may lack substantial atmospheres. The habitable-zone planets (TRAPPIST-1e, f, g) are scheduled for extensive transit observations, but obtaining atmospheric composition constraints will likely require cumulative observations spanning multiple JWST observing cycles.
